1-10 Volt Dimming Switch
The 1-10 volt dimming switch is suitable for low voltage dimmable LED filament bulbs. This dimmer comes without a switch wall plate as it is designed to be retrofitted to your existing switch wall plate.
Technical Details
| Product Number | 1-10DIM |
| Working ambient temperature | 0 ~ 50°C |
| Max LED drivers per dimmer | 30 |
| Connection type | Screw terminal |
| Dimensions | 22.5 x 22.5 x 28.6 mm |
| Warranty | 12 months |
Important Warning
-
Disconnect power before installation.
-
Two or more dimmers cannot be connected in parallel, or series to control the same load.
-
Ensure the positive and negative connections have been made correctly.
